I’ve been living with the Solaris for a week or so now and I am loving its detail, soundstage, and just sheer musicality. You start off listening to the HiFi but very quickly get drawn in and are soon just loving the music. This is an excellent and very well featured amplifier. It sounds and looks marvellous.
Best Ampliifer
OTL – transformer out less tube amplifier (design 1982)
Double mono design
Power output: each channel 12W at 220Ω load in OTL mode
Bandwide: 15 to 100,000 Hz
Damping: 3600！
Sensitive ratio: 100dB
Distortion 0.002% at 1Watt – 220Ω load
Max. OTL – mode: output 120 VAC
Max. STAX – mode: output 480 VAC
Gain: OTL mode 34dB, STAX + 12dB by output transformer ratio
Gain switch for all modes: + 8 dB
Input sensitivity: 0dB, resistant 47KΩ
Bias voltage: 300 + 580 VDC
IC – full automatic – controlled bias – class – a mode
Patent full automatic servo tube biasing
Power consumption: max. 100 watt
Size 360 x 320 x 140 mm (D.W.H)
Weight: 10 kg
| LOW IMPEDANCE mode:
Test load 4Ω: (6 Watt an 8Ω/channel) bandwide: 15 – 100.000 Hz damping: 15 min. load 4 Ω gain IMP: 34dB – 15,5 dB = 18,5 dB gain Stax: 34dB – 9,5dB = 24,5 dB |
OTL mode:
Test load 220Ω. ( 8 Watt an 100-400Ω/channel) bandwide: 12 – 150.000 Hz damping: 3200 (220 Ω) gain 0: 34 dB gain +: 42 dB max. load 2000 Ωs |
STAX mode:
( Step-UP-transformer ) bandwide: 15 – 100.000 Hz Bias: 300V+580 VDC Vout: max: 470 VAC rms gain IMP 0: 34 dB + 6 dB = 40 dB gain IMP +: 42 dB + 6 dB = 48 dB gain Stax 0: 34dB +12 dB= 48 dB gain Stax +: 42dB +12 dB= 54 dB |
Gain overview
Mode: Low-Imp
Impedance turning switch start works in three stages on this mode only.
Signal on all black headphone jacks, 18.5dB and impedance turning switch, max 26.5dB
STAX summary: 34dB + impedance turning switch, max. 48dB.
Mode: (blue) OTL, summary: 34dB (amplifier gain only, step – up transformer less) – STAX connector do not have signal supported. Output transformer is not in use.
Mode: (yellow) STAX only, summary: 54dB
(34dB +8dB GAIN+ +12dB galvanic coupled) all other jacks not output signal supported.
