Mytek Brooklyn Bridge II（4TB)

US$4,995

Review:

Conclusion Mytek Brooklyn Bridge II – One of a kind

The new Mytek with Roon Core deserves an extra star for its successful combination of music server and streamer in a compact housing. At the same time, it makes no compromises in terms of sound or performance. And in view of the practical results, the asking price is also fully reasonable, even to be regarded as cheap. Similarly good-sounding and high-performance combinations of separate Roon Core and Streamer cost at least as much, if not more.

https://www.lowbeats.de/test-mytek-brooklyn-bridge-ii-mit-integriertem-roon-core-der-erste-einer-neuen-art/

Description

BROOKLYN BRIDGE II ROON CORE

ALL-IN-ONE • ROON CORE STREAMER • DAC • HEADPHONE • PHONO• PREAMP

Brooklyn Bridge 2 is all in-one Roon Core Streamer + excellent DSD/MQA DAC+ Analog (w/Phono) and Digital Preamp and a high-end headphone amplifier in a compact, modern beautiful chassis. It connects all your music sources in a highest sound quality hub before sending the music to amp and speakers or headphones. It’s powered by modern touch operated software – Roon for music browsing and streaming and Mytek OS for all other functionality. Software controls available on front panel are repeated on a wifi device: tablet or smartphone for comfort and convenience.

SPECIFICATIONS :

Built in Roon Core: Tidal, Qobuz and local library in any format up to PCM 384kHz, DSD256 and MQA

Analog Preamp: Phono M/C and M/M and line RCA input

Digital Preamp: SPDIF and Optical inputs for disk players, or TV,

Roon Ready DAC input for use w another streamer when required

Bluetooth 5: including hi-res audio (quality depends on cellphone) – For quick casual listening to any internet sound/music source.

CONVERSION

up to 384k, 32bit PCM, native DSD up to DSD256, DXD, 130dB DR, ES9028PRO chipset with superior Mytek implementation (HAT ™ Harmonic Audio Tuning)

MQA HI-RES DECODER

DECODER: built in hardware MQA decoder, full unfold to original sample rate

DIGITAL DAC INPUTS

USB2 Class2 (OSX, Linux driverless, all formats up to 384k, DSD256), 2x S/PDIF, 1 Toslink optical (PCM up to 24/192k, up to DSD64 DOP, MQA)

ADDITIONAL DIGITAL INPUTS

Bluetooth 5 and Roon Ready Network Endpoint DAC input- PCM384k, DSD256, MQA.

ANALOG PREAMP INPUTS

Line level input (10k input impedance) or Phono M/M, relay controlled. All analog signal path to output.

2xUSB3/2 connectors

Can be used for:

1) Any music files on FAT /NTFS / Exfat drive or USB Stick. SSD is recommended because of 1A current limit)

2) additional USB DACs for additional Roon Zones (2pcs or up to several can be connected if USB hub is used)

ANALOG OUTPUTS

RCA, balanced XLR, simultaneous, 10 Ohm output impedance

CLOCK

Mytek Femtoclock Generator(tm) 0.82ps internal jitter

HEADPHONE OUTPUTS

Reference High Current, High transient Headphone Amp, 500mA, 6 Watts, dual headphone jacks, designed to drive hard to drive headphones. Balanced operation with a 1/4″ to 4 pin XLR adapter

VOLUME ATTENUATOR

Choice of 1dB step analog attenuator,  or 1dB step digital 32 bit attenuator and purist relay bypass.

INTERNAL STORAGE

4TB of internal SSD (approx 625 CDs). Internal storage is part of the system SSD on the main CPU board and it is fixed and not user upgradable. Internal storage is accessed by the user as a network drive.

POWER SUPPLY

90W Toroidal Linear Power Supply powers the DAC and the Intel  I5 CPU from separate windings. Auto voltage detection adjusts to the local line voltage (90-240VAC 50/60Hz)

WEIGHT

6lbs, 3kg

WARRANTY

2 years

DIMENSIONS

WxDxH=8.5×8.8×1.74”=216x225x44mm

WEIGHT

6lbs, 3kg

WARRANTY

2 years

Specifications are subject to change.
